SSR 40DA DC Control AC 40A Three Phase Solid State Relay

Solid State Relays Load Current 40A Load Voltage 480VAC Control Voltage 3 32VDC Control Current DC:10 68mA On voltage 2VAC Off Leakage Current 10mA On off Time 10ms Dielectric Strength 2500VAC Insulation Resistance 1000M 500VDC Ambient Temperature 30 75 Mounting Methods Bolting The work instructions LED 600V Transient Capability Low EMI EFI & Surge byzero crosstrigger control High Isolation over than50M 500VDC Theory : Solid State Relay Protect Feature : Sealed is customized : Yes Usage : General Purpose Contact Load : Low Power Model Number : SSR3P 40DA
