20Nm Intelligent Electric Control Actuator Analog 0 5V 0 10V 4 20mA Proportional Valve 220V 24V for Water Regulating AC230V 4 20MA, Stem 11X11mm

Solenoid Control Valves Specifications: Actuator material: ABS die casting aluminum Customization required Torque force:20 Nm Manual operation:Yes Open close indicator: Yes Protection class: IP67 Connection standard:ISO5211 F05 F07 Stem sizes:14X14MM Matched valves:2 way 3 way ball valve and butterfly valve Rated voltage: AC DC24V AC95 265V Control signal: 4 20mA 0 20mA 0 5V 1 5V 0 10V 2 10V Position feedback:4 20mA 0 5V0 10V Cable Length: 0.5m Hign concerned Chemical : None Actuator Mode : With Manual And Instruction Structure : Regulating Port Size : 1 4" to 3" Media : Water Material : Plastic Standard or Nonstandard : Standard Pressure : Medium Pressure Model Number : TFM02T 24 220 Power Source : AC Is Smart Device : no Origin : Mainland China Certification : CE Actuator Voltage : ACDC24V or AC230V Actuator Torque : 20Nm Control Signal : 0 5V 0 10V 4 20mA Actuator Material : ABS Die casting Aluminum Flange face : ISO5211 F03 F04 F05 Protection class : IP67 Certification : CE Gears : All Metal Gears
